Let’s Encrypt on ISPConfig

Let’s Encrypt is a free SSL certificate authority. ISPConfig has built-in support for issuing and managing Let’s Encrypt SSL certificates for websites, mail, and services.

It uses acme.sh or certbot (depending on version) to automatically request and renew SSL certificates.




Prerequisites:

  • ISPConfig Version: Ensure you’re using ISPConfig version 3.1 or later, as it has built-in support for Let’s Encrypt.
  • Domain Name: You must have a valid domain name configured for your website and it must be pointed to your server’s public IP address.
  • Web Server: ISPConfig supports both Apache and Nginx as web servers. Ensure one of them
  • is properly installed and running.


1) Configure DNS for Your Domain:

  • Ensure that the domain name (e.g., yourdomain.com) has proper A (and optionally AAAA) DNS records pointing to your server’s IP address.
  • You can check your DNS configuration with a tool like DNSstuff or dig.




2) Enable Let’s Encrypt in ISPConfig: Do the following steps:

  • Log in to ISPConfig using the admin interface (https://your-server-ip:8080).
  • Navigate to Sites > Websites.
  • Select the website you want to enable SSL for.
  • Under the SSL tab, find the option to “Use SSL”.
  • Check the box for “Let’s Encrypt SSL”.
  • Optionally, enable “Force SSL” if you want all traffic to be redirected to HTTPS. Then save the settings.

3) a Let’s Encrypt SSL Certificate: Once you enable Let’s Encrypt for your website, the following will occur:

  • In the Website settings, after checking Let’s Encrypt, ISPConfig will automatically attempt to issue a certificate for your domain.
  • It will use the Webroot method (HTTP-01 challenge) by default, which requires that the domain is publicly accessible and points to the server.
  • If DNS and your web server are configured properly, ISPConfig will successfully request the SSL certificate from Let’s Encrypt.

4) Verify SSL Installation: After the certificate is issued, verify that SSL is working by doing these steps:

  • Check in the ISPConfig Interface: In the Website settings under the SSL tab, you should see that the SSL certificate is active and has the expiry date of the certificate.
  • Check on the Browser: Visit your website (https://yourdomain.com) and ensure the site is loaded with HTTPS, and check for a padlock symbol in the address bar indicating that the connection is secure.
  • You can also use tool like SSL Labs’ SSL Test to verify the SSL installation.

  5) Set Up Auto-Renewal:

  • Let’s Encrypt certificates are valid for 90 days, so it’s important to set up auto-renewal. ISPConfig automatically handles the renewal process, but it’s good to verify that everything is set up correctly.
  • ISPConfig should automatically renew the certificate before expiration. It checks and renews the certificates when the website is reloaded, or the server is restarted.
  • You can check the status of auto-renewal by navigating to Sites > Websites, selecting the domain, and verifying that the Let’s Encrypt SSL certificate is renewed.

6) Force HTTPS (Optional): If you want to ensure that all traffic to your website uses HTTPS, you can set up an HTTP to HTTPS redirect by doing these steps:

  • In the ISPConfig panel, under the website configuration, enable the “Force SSL” option. This will automatically redirect all HTTP traffic to HTTPS, ensuring that users always connect securely.
  • Alternatively, you can manually configure a redirect in your web server’s configuration file by doing the following steps:
  • Apache: Add the following to your htaccess file or virtual host using the following commands:
  • RewriteEngine On
  • RewriteCond %{HTTPS} off
  • RewriteRule ^ https://%{HTTP_HOST}%{REQUEST_URI} [L,R=301]
  • Nginx: In your Nginx server block, add the following:
  • server {
  • listen 80;
  • server_name yourdomain.com www.yourdomain.com;
  • return 301 https://$server_name$request_uri;
  • }

   7) Troubleshooting Let’s Encrypt Issues: If the certificate isn’t issuing, consider these  common issues:

  • DNS Resolution: Ensure the domain’s DNS is correctly pointing to your server’s public IP address.
  • Web Server Accessibility: Make sure ports 80 (HTTP) and 443 (HTTPS) are open in your firewall and that your web server is accessible from the Internet.
  • Server Configuration: If using Nginx or Apache, ensure your server is correctly configured to serve the domain and that it’s not misconfigured (e.g., not blocking HTTP traffic).
  • Rate Limits: Let’s Encrypt has rate limits (e.g., 5 requests per week per domain). If you hit the rate limit, wait for the limit to reset or try using a staging environment for testing.

  8) Manual Renewal (if needed):

  • In some cases, you might need to manually renew the certificate. You can do this by running the following command on your server:
  • ispconfig_update.sh–letsencrypt-renew
  • This command renews all Let’s Encrypt certificates managed by ISPConfig.

  9) Testing SSL Renewal:


  • After the certificate renewal, check the expiry date of the SSL certificate in the ISPConfig interface or in a browser to verify that the renewal has been successful.
